ZXR10 GER (V2.6.03) General Excellent Router User Manual Volume-I
114 Confidential and Proprietary Information of ZTE CORPORATION
Command
Format
Command
Mode
Command Function
e1< E1
number >
clock
source
Result: This sets the clock source of E1 channel.
5. To set frame as a sonet, use sonet command in interface
configuration mode, as shown in
Table 135.
TABLE 135 S ONET FRAMING
Command
Format
Command
Mode
Command Function
sonet
Interface
config
This sets the framing as a sonet
Result: This sets the framing as a sonnet.
6. To enter into the sts-1 configuration mode, use sts-1
command in global configuration mode, as shown in
Table
136.
TABLE 136 STS-1 COMMAND
Command
Format
Command
Mode
Command Function
sts-1 global config
This enter into the sts-1
configuration mode
Result: This enters into the sts-1 configuration mode.
7. To select the mapping mode of sts-1, vt-15 or vt-2, use
mode command in interface configuration mode, as shown
in
Table 137.
TABLE 137 MODE COMMAND
Command
Format
Command
Mode
Command Function
mode
Interface
config
This select the mapping mode
of sts-1, vt-15 or vt-2
Result: This select the mapping mode of sts-1, vt-15 or vt-2.
E
ND OF STEPS
E1 Encapsulation-VT-2
Refer to below procedure for configuring E1 encapsulation in
case of VT-2 ZTE ZXR10 GER router.
Router Command Line Interface has been accessed.
Purpose
Prerequisite
