Chapter 6 Interface Configuration
Confidential and Proprietary Information of ZTE CORPORATION 113
TABLE 131 TUG-3 CONFIG MODE
Command
Format
Command
Mode
Command Function
au-4 1 tug-
3
Interface
config
This enables to enter into the
tug-3 configuration mode
Result: This enables to enter into the tug-3 configuration
mode.
2. To set the framing format of E1 channel, use tug-2<Vtg
number > e1< E1 number > framing command in interface
configuration mode, as shown in
Table 132.
TABLE 132 E1 FRAMING FORMAT
Command
Format
Command
Mode
Command Function
tug-2<Vtg
number >
e1< E1
number >
framing
Interface
config
This sets the framing format of
E1 channel
Result: This sets the framing format of E1 channel.
3. To create a CPOS interface in the E1 encapsulation format,
use tug-2<Vtg number> e1< E1 number > channel-group
1 timeslots <1-31> command in interface configuration
mode, as shown in
Table 133.
TABLE 133 E1 CPOS INTERFACE
Command
Format
Command
Mode
Command Function
tug-2<Vtg
number>
e1< E1
number >
channel-
group 1
timeslots
<1-31>
Interface
config
This creates a CPOS interface in
the E1 encapsulation format
Result: This creates a CPOS interface in the E1
encapsulation format.
4. To set the clock source of E1 channel, use tug-2<Vtg
number> e1< E1 number > clock source command in
interface configuration mode, as shown in
Table 134.
TABLE 134 E1 CLOCK SOURCE
Command
Format
Command
Mode
Command Function
tug-2<Vtg
number>
Interface
config
This sets the clock source of E1
channel
