Chapter 3 Structure and Principles
Confidential and Proprietary Information of ZTE CORPORATION 15
FIGURE 8 ZXR10 GER04 HARDWARE STRUCTURE
Service interface card
1#
Service interface card
2#
Service interface card
3#
Service interface card
4#
Power module 1# Power module 2#
System main control module 1#
System main control module 2#
F
A
N
ZXR10 GER08 Hardware Structure
Figure 9 shows ZXR10 GER08 hardware structure.
FIGURE 9 ZXR10 GER08 HARDWARE STRUCTURE
Service interface card 1# Service interface card 2#
Service interface card 3# Service interface card 4#
Service interface card 5# Service interface card 6#
Service interface card 7#
Service interface card 8#
System main control module 2#
System main control module 1#
Power module 2#
Power module 1#
ZXR10 GER System
Architecture
ZXR10 GER system architecture topics are described in below
table.
Topic Page No
ZXR10 GER02/04 SMNP 16
ZXR10 GER02/04 SMNP Panel 15
ZXR10 GER08 SMP 19
ZXR10 GER08 SMP Panel 20
