ZXR10 GER (V2.6.03) General Excellent Router User Manual Volume-I
360 Confidential and Proprietary Information of ZTE CORPORATION
ZXR10_R2(config-
i
f)#ip address 10.10.40.1
255.255.255.0
ZXR10_R2(config-if)#ip pim sm
ZXR10_R2(config)#interface fei_1/3
ZXR10_R2(config-
i
f)#ip address 10.10.50.1
255.255.255.0
ZXR10_R2(config-if)#ip igmp access-group 10
ZXR10_R2(config)#router ospf 1
ZXR10_R2(config-ro
u
ter)#network 10.0.0.0
255.0.0.0 area 0.0.0.0
ZXR10_R2(config)#ip multicast-routing
ZXR10_R2(config)#router pimsm
ZXR10_R2(config-router)#rp-
c
andidate loopback1
priority 20
ZXR10_R2(config-router)#bsr-
c
andidate loopback1
10 20
ZXR10_R2(config)#access-list 10 permit any
R3 configuration:
ZXR10_R3(config)#interface loopback1
ZXR10_R3(config-
i
f)#ip address 10.1.1.3
255.255.255.255
ZXR10_R3(config)#interface fei_1/1
ZXR10_R3(config-
i
f)#ip address 10.10.30.2
255.255.255.0
ZXR10_R3(config-if)#ip pim sm
ZXR10_R3(config)#interface fei_1/2
ZXR10_R3(config-
i
f)#ip address 10.10.40.2
255.255.255.0
ZXR10_R3(config-if)#ip pim sm
ZXR10_R3(config)#router ospf 1
ZXR10_R3(config-
r
outer)#network 10.0.0.0
255.255.255.0 area 0.0.0.0
ZXR10_R3(config)#ip multicast-routing
ZXR10_R3(config)#router pimsm
ZXR10_R3(config-router)#rp-
c
andidate loopback1
priority 30
ZXR10_R3(config-router)#bsr-
c
andidate loopback1
10 30
Assign R1 and R3 as a PIMS-SM domain and R2 as another
PIMS-SM domain, and then enable the multicast data streams of
the two PIMS-SM domains to inter-work through the MSDP.
R1 configuration:
MSDP
Configuration
Example
