4.5.2 Replacing the serial measurement unit
Location of serial measurement unit
The serial measurement unit is located inside the base of the robot, as shown in
the figure.
A more detailed view of the base may be found in the spare part view, see Spare
parts - Base, exploded view.
xx0500001390
Base cover, including gasket. Serial measurement unit is located beneath the
cover.
