163
MC97F
60128
A
BOV Semiconductor Co., Ltd.
TINTCR(T
imer Interrupt Cont
rol Register)
:
4004H (
XSFR)
7
6
5
4
3
2
1
0
–
–
T2MIE
T1MIE
T0MIE
T2OVIE
T1OVIE
T0OVIE
–
–
R
/
W
R
/
W
R
/
W
R
/
W
R
/
W
R
/
W
Initial value
:
00H
T2MIE
Enable or Disable Timer 2 Match Interrupt
0
Disable
1
Enable
T1MIE
Enable or Disable Timer 1 Match Interrupt
0
Disable
1
Enable
T0MIE
Enable or Disable Timer 0 Match Interrupt
0
Disable
1
Enable
T2OVIE
Enable or Disable Timer 2 Overflow Interrupt
0
Disable
1
Enable
T1OVIE
Enable or Disable Timer 1 Overflow Interrupt
0
Disable
1
Enable
T0OVIE
Enable or Disable Timer 0 Overflow Interrupt
0
Disable
1
Enable
162
164
