Service Manual – Installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
99
7.4.3
Ceph arm covers
Figure 38
The posterior cover is simply attached by magnets.
Figure 39
Push
to lock
