11.3 Parts replacement
11.3.1 Fuses replacement
Before replacing fuses, turn the unit OFF and disconnect it from the mains (by
turning OFF the mains power supply breaker dedicated to the unit).
Replace the broken fuse with one of the same specification.
11.3.1.1 Main fuses
The main fuses F1 and F2 are located on the top side of the unit.
The fuse F1 cuts the mains supplied to the switching power supply (G1) in case of
overcurrent.
The fuse F2 cuts the mains supplied to the motor column driver (G2) in case of
overcurrent.
Fuses type:
• F1: 6.3x32 F fuse. Refer to chapter 5 – Technical Characteristics – for the value
• F2: 6.3x32 F fuse. Refer to chapter 5 – Technical Characteristics – for the value.
11.3.1.2 MCU board (A1) fuse
The MCU board fuse F1, in case of overcurrent, cuts the 24V supplied to the motors
(M3, M4, M5, M6) .
Note
It does not cut the 24V supplied to the 3D sensor power board (A10).
Fuse type: 2 A FF (125V)
Refer to chapter 12 – drawing 2 – for fuse position.
