14. APPENDIX
14.1 Appendix A: Setup parameters table
The following table lists those adjustment parameters stored in the unit during
factory testing and that must be re-entered into the non-volatile memory in case of
replacement of the MCU board (A1). This is due to the fact that the new MCU board,
provided as a spare part, has been factory tested from the functional point of view,
but contains only default parameters which are not related to the unit where it will
be installed.
Entering of the listed parameters can be performed through the service programs
(see chapter 8).
Note
The information listed in the table are the technical parameters set during
factory testing. Preferences set by the user (e.g. exposure parameters
different than the default ones) are not listed.
The table also has columns with blank cells. These cells must be filled in when,
during installation or during the life on the unit, any of the listed parameters will
be modified (e.g. after replacing a motor or a positioning sensor).
