Service Manual – Troubleshooting
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
153
9. TROUBLESHOOTING
Note
If components have to be replaced or technical support is required, contact
Technical Service providing the mandatory information listed on
paragraph 1.2 and the additional information required by the specific error
description.
9.1 LEDs
9.1.1 MCU board A1 LEDs
The following table shows the LEDs that are present on MCU board A1, their
functions and the recommended corrective actions in case of defects. To locate the
LEDs, refer to the layout of the MCU board A1 (see chapter 12 – drawing 2).
Led
Colour
Working
status
Failure
status
Main function
Corrective action
H1
Green
ON
OFF
+24V
See paragraph
11.2.3
H2
Green
ON
OFF
+24V Motors
and power
supply
See paragraph
11.2.3
H3
Green
ON
OFF
+5V
Check cables:
X22, X23, X24, X36,
X15, X10, X25, X9
H4
Green
ON
OFF
+ 3V Micro
controller
power supply
H5
Green
ON
OFF
Laser power
supply
Check the laser
cables X16 and X18
H6
Green
Flashing /
lit weakly
Steady ON/OFF
= error on
CANbus
Can Bus
communication
See Error
E670 and E671
(paragraph
9.2.6.11)
H7
Red
Flashing /
lit weakly
Steady
ON/OFF= error
on CANbu
s
Can Bus
communication
See Error
E670 and 671
(paragraph
9.2.6.11)
H8
H9
H10
Green
OFF
These three
LEDs when
blinking
