Acteon X-MIND prime 3D ceph - Cable; TOP Side; Rotation Arm Cables

Service Manual – Spare parts
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
359
13.5.2 Cable
Ref.
Order code
Description
Note
--
6204043200
X-ray push button with cable
--
6204011400
Chin rest signal cable X12-X24-X36 /
X46-X47 X1B4
--
6204011500
Chin rest motor cable X20 / X49
--
6204101200
Power switching cable J1
--
6204101000
Power cable
--
6204101100
Signal & Rx cable X8-X51 / X10-X13
--
5007080200
Ethernet cable CAT 6
13.6 TOP side / Rotation arm cables
Ref.
Order code
Description
Note
--
6204040500
Laser 1 cable X16
--
6204040600
Laser 2 cable X17
--
6204040100
HF board power supply cable Z1 /
X31
--
6204040200
HF board signals cable X15 / X32
--
6204041800
Power Sensor 3D board cable X11 /
X37
--
6204042600
Collimator signal cable X59/X77
--
6204042700
Collimator power cable X67/X75
--
6204042800
Collimator motor signal cable
X66/X76
--
6204043000
Signal pan sensor cable X61/X38
--
5004040300
Ethernet cable CAT 6
