Acteon X-MIND prime 3D ceph - Collimator

Service Manual – Spare parts
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
355
13.3 Collimator
1
5804060200
A12 - Collimator driver board
2
5804060400
Optical sensor board
3
5704060100
Traction spring T31030 DIM
4
6204060100
Horizontal sensor motor cable
5
6204060200
Vertical sensor motor cable
6
6204060300
Horizontal motor 1
7
6204060400
Horizontal motor 2
8
6204060500
Vertical motor 3
9
6204060600
Vertical motor 4
2
6
7
3
3
1
8
9
2
4
5
