10.1 Service tools
In order to perform a correct system calibration, is necessary the use of the
following tools:
Code
Description
Function
6107900100
Laser centering tool
Laser alignment check
6195170100
Support plate
Support for panoramic and 3D
centering tools
6195170200
Centering tool
Panoramic function adjustment
5207900900
Centering cylinder
3D function adjustment
5607900800
1.5mm copper filter
Sensor calibration
