Service Manual – Pre-installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
6.1
Electrical setting up
The main electrical characteristics of X-Mind Prime 3D are:
•
Single-phase grounding supply 110-240 V ~
•
Frequency 50/60 Hz
•
Power consumption 1.8 kVA (at 115 V)
1.4 kVA (at 230 V)
•
Current consumption 14.5 A (at 115 V)
6 A (at 230 V)
•
Apparent line resistance 0.2 Ω (96-197 V)
0.5 Ω (197-264 V)
•
Line voltage regulation < 3 % at 99 V
Warning
The unit is classified as
“Permanently Installed”
according to EN 60601-1,
meaning that the mains cable shall be permanently connected to the mains
line.
DO NOT connect the unit to the power using a detachable plug , to
avoid compromising the electrical safety.
Warning
The unit is classified as
“IPX0”
according to EN 60529, meaning that the
units provides
NO protection against the ingress of liquids
The unit must be connected to a differential magneto-thermal switch, to
separate the unit from the mains line in case of maintenance operations. This
switch must comply with the electrical regulations in force in the country of
installation.
The unit comes equipped with a 3-meters mains connection cable (13 AWG, 2.63
mm
2
) already connected to the unit mains terminals.
The installer is responsible for verification of the mains line characteristics in the
installation site. The minimum recommended wire gauge is:
•
1.5 mm
2
(16 AWG) for 200-240Vac nominal range power supply input.
•
2.63 mm
2
(13 AWG) for 110-200Vac nominal range power supply input.
The general grounding must comply with the rules in force; a wrong quality of the
grounding could be dangerous for the patient and operator’s safety and might
cause malfunction of the unit.
