11.3.2 MCU board replacement
Warning
The board shipped as replacement carry the Hardware key and the
EEPROM not configured.
To make the system working, the Hardware key must be retrieved from the failed
board and positioned on the new board. This component includes the U.I.C.
(Unique Identification Code) which determines the enabling codes for the
radiological exams.
Moreover, on the EEPROM has stored the system configuration data; remove the
EEPROM from the new board and replace it with the one present on the failed
board. In case the old EEPROM was not functioning, it will be necessary to mount
the not configured EEPROM and restore manually the configuration data present
on the equipment parameters table supplied with the Service Manual (see
paragraph 14.1), following the procedure present on chapter 8 – “Service programs
description”.
Note
At the end of the replacement, restore the metallic cover verify that thee
firmware is compatible with the firmware of the other boards and with the
ASP driver.
If you have any doubt contact the technical service.
