Acteon X-MIND prime 3D ceph - Power Sensor Board A10 Leds; CCU Ceph Control Board A11 Leds

Service Manual – Troubleshooting
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
155
- Bad mA / kV
feedback
- X-ray button
release
H6
Yellow
OFF during
stand-by
ON during
X-ray
ON during
stand-by
OFF during
X-ray
X-ray emission
active
H8
Green
ON
OFF
Auxiliary power
supply
See Error E750
(paragraph 9.2.7.1)
H9
Red
OFF
ON
X-ray exposure
too long (backup
timer
intervention)
See Error E755
(paragraph 9.2.7.6)
H10
Green
ON
OFF
Main power
supply
See Error E750
(paragraph 9.2.7.1)
9.1.3 3D Power Sensor board A10 LEDs
The following table shows the LED that is present on the 3D Power Sensor board
(A10), its function and the recommended corrective action in case of defect. To
locate the LED, refer to the layout of the A10 board (see chapter 12 – drawing 4).
Led
Colour
Working
status
Failure
status
Main function
Corrective action
H2
Green
ON
OFF
8/9V 3D sensor
power supply
See Error E1402
(paragraph
9.2.10.2)
9.1.4 CCU Ceph Control Board A11 LEDs
The following table shows the LEDs that are present on the CCU Ceph Control Board
(A11), their function and the recommended corrective action in case of defect. To
locate the LED, refer to the layout of the A11 board (see chapter 12 – drawing 5).
Led
Colour
Working
status
Failure
status
Main function
Corrective action
H1,
H2
Green,
Red
Flashing/
lit weakly
Steady
ON/OFF=
error on
CANbus
CANbus
communication
Check cable X9
