Service Manual – Installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
97
7.4
How to mount the covers
Note
Cover mounting is easier with the unit powered ON, mainly to move lift.
7.4.1
Wall plate cover
Figure 35
Posterior bracket and cables cover
