Acteon X-MIND prime 3D ceph - CEPH Arm and Mobile Sensor; Electrical - Mechanical Part & Cables

Service Manual – Schematics and drawings
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
362
13.8 CEPH Arm and Mobile Sensor
13.8.1 Electrical - mechanical part & cables
Ref.
Order code
Description
Note
1
6204080300
Ceph collimator motor with cable
X93
2
6204080400
Ceph sensor motor with cable X92
3
5804080200
A13 - Driver Ceph board
4
6204080500
Nasion potentiometer with cable X94
5
6204080600
Ceph motor sensor cable
6
5404081312
Brake lever
7
4990804800
Open belt 10 T2.5 roll 1.025m
8
5711418800
Traction spring 6,6x33,5x0,7
9
4910322900
Radial bearing 4x13x5
10
6107080700
Nose rest group
11
6104080900
Right head support Assy
12
6104081000
Left head support Assy
13
4990806900
Belt
14
5404070400
Fixed part sensor connection
15
5804070600
A15 - Fixed Pogo-pin board
--
6204080800
Signal ceph cable X58 / X89
--
6204080900
Signal motor ceph cable X54 / X88
--
6204081000
Power ceph cable X53 / X87
--
6204080700
Signal sensor ceph cable X96 / X96
--
5007080200
Ethernet cable CAT 6
--
6104081300
Hand support plate for carpus exam
