Acteon X-MIND prime 3D ceph - 13 Spare Parts; Top Side of the Unit; Electrical and Mechanical Part

Service Manual – Schematics and drawings
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
350
13. SPARE PARTS
13.1 Top side of the unit
13.1.1 Electrical and mechanical part
Ref.
Order code
Description
Note
1
6204041000
Light sensor assy Y axis
2
6204040900
Light sensor assy rotation
3
6604041200
Y axis motor assy
4
4990807000
Y movement belt
5
5804040700
A1 - CPU (MCU) board
6
4492824900
G1 - Power supply board
7
4291421400
Emergency pushbutton
8
4291422000
ON/OFF Switch
9
4192212200
Mains filter
10
5804040800
A11 CCU board
11
6604041100
Rotation motor assy
12
4990806900
Rotation belt
13
6104042100
Fuse kit wide range
14
4695456700
5 port Gigabit Switch
15
5804041000
Optical sensor board Ceph position
