Acteon X-MIND prime 3D ceph - Electrical Connections

Service Manual – Installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
92
7.3 Electrical connections
All external connections are located in the base of the unit.
Mains Power Supply :
The mains line shall be connected to the terminal block on the right side of the
unit. The power supply cable is already connected inside the X-Mind Prime 3D. It is
only necessary to connect it to the dedicated power supply line.
Note
Before to connect main power supply, be sure that the main provided by
the Customer is according to specification in terms of voltage, line
resistance and safety protections (see paragraph 6.1).
