6.2 Packaging
The unit is delivered on one pallet containing three cardboard boxes
Contents
Packing dimension
Weight
Net
Gross
Complete unit
150x100x H145 cm
(59.1”x39.4”x57.1”)
143 kg
(315 lbs)
198 kg
(436 lbs)
Main unit
122x100x H63 cm
(48”x39.4”x24.8”)
101 kg
(223 lbs)
130 kg
(287 lbs)
Ceph arm
150x92x H66 cm
(59.1”x39.4”x26”)
22 kg
(48 lbs)
26 kg
(57 lbs)
Workstation
100x26x H63 cm
(39.4”x10.3”x26”)
20 kg
(44 lbs)
22 kg
(48 lbs)
Ceph arm
Main unit
Workstation
