Acteon X-MIND prime 3D ceph - Covers

Service Manual – Schematics and drawings
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
360
13.7 Covers
Ref.
Order code
Description
Note
1
5604101405
Rear base cover
2
5604101505
Base cover
3
5604101605
Duct
4
5604101705
Upper cover
5
5604103305
Lateral cover
6
6604020305
Rotating arm lower cover
7
6604020805
Sensor internal cover
8
6604020921
Sensor external cover
9
6604020205
Tube head internal cover
10b
6604020621
Tube head external cover with logo
11
6604041105
Upper cover
12
5404090205
Lower guard 3D chin rest arm
