Note
Although it is recommended to use the package as a tool to install the X-
Mind Prime 3D, here following the indication of the drill layout for the
standard height in case it is necessary to prepare the room before you
receive the unit.
The unit can be fixed in different ways:
•
To the wall only, using the upper bracket (2 screws) and lower
bracket (2 screws)
•
To the wall and floor using the upper bracket (2 screws), lower
bracket (2 screws) and the floor plate (4 screws). This installation is
recommended when the wall strength is uncertain.
•
A 16” bracket adapter is available for dual-stud installation on
wooden walls.
Note
A free-standing floor plate is also available for installations where drilling
holes in the walls is not possible. Although this kind of installation provides
the necessary structural safety, the unit might have higher vibrations and
oscillations.
Warning for free standing floor mounted unit
In case the unit shall be moved for service or other extraordinary operation,
maximum caution shall be taken to prevent the unit from tilting and falling to the
ground.
