2.6 Symbols used
In this manual and on X-MIND prime 3D itself, apart from the symbols indicated on
the keyboard, the following icons are also used:
Symbols
Description
Device with type B applied parts
Some parts of the device contain materials and liquids that,
at the end of the unit's lifecycle, must be disposed of at
appropriate disposal centres.
~
A.C. voltage
N
Connection point to the neutral conductor
L
Connection point to the line conductor
Protection grounding
Functional grounding
OFF; device not connected to the mains

ON; device connected to the mains
Laser
Dangerous voltage
Product identification code
Serial number
Manufacturing date (year and month)
Name and address of the manufacturer
Filtration
Tube-head
X-Ray tube
