Service Manual – Technical characteristics
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
39
5. TECHNICAL CHARACTERISTICS
General features
Type
X-MIND prime 3D
Manufacturer
de Götzen S.r.l.
21057 Olgiate Olona (VA) - Italy
Class
Class I with type B applied parts
according to IEC 60601-1
classification.
Protection degree
IPX0 standard device
Line voltage
99-264 V
Rated line voltage
110-240V
Line frequency
50/60Hz
Maximum line current
14.5 A @115V 50/60Hz
6 A @ 230V 50/60Hz
Technical factors for maximum line
current
86kV, 12.5mA
Power consumption
1.8kVA @ 115V 50/60Hz
1.4kVA @ 230V 50/60Hz
Protection fuse (F1)
20 A T 250V 6.3x32 mm 10kA@125V
8 A T 250V 6.3x32 mm 200A@250V
Column protection fuse (F2)
4 A T 250V 6.3x32 mm 10kA@125V
2.5 A T 250V 6.3x32 mm 100A@250V
Maximum line apparent resistance
0.2 Ω (96-197 V)
0.5 Ω (197-264 V)
Rated output voltage (kVp)
60 – 86kVp, with 2 kVp steps
Anodic current
2 – 12.5mA, with R20 scale steps (2, 2.2,
2.5, 2.8, 3.2, 3.6, 4, 4.5, 5, 5.6, 6.3, 7.1, 8,
9, 10, 11, 12.5)
Additional filtration
≥ 2 mm Al eq.
