Exposure times
Panoramic exam (PAN)
14 s Adult / 12.8 s Child
Half panoramic exam
7.7 s Adult / 7.1 s Child
Ortho Rad panoramic exam
11.5 s Adult / Child
Low dose panoramic exam
11.6 s Adult / 10.4 s Child
Frontal dentition
4.1 s Adult / Child
Bitewing Right, Bitewing Left
3.1 s Adult / Child
Bitewing Right & Left
6.2 s Adult / Child
TMJ mouth closed/open
10.6 s for left and right joint in open and
closed condition
TMJ single phase
5.3 s
Sinus P/A projection
9 s
3D exams (except TMJ 3D)
7 s
TMJ 3D
6.2 s
Latero lateral 18x24 and 18x18
cephalometric exam
9.1 s HD / 4.4 s HS
Latero lateral 24x24 and 24x18
cephalometric exam
12.1 s HD / 5.8 s HS
Latero lateral 30x24 and 30x18
cephalometric exam
15.1 s HD / 7.3 s HS
Antero posterior 24x24 and 24x18
cephalometric exam
12.1 s HD / 5.8 s HS
Carpus
4.5 s
Exposure time accuracy
± 5 % or ± 20ms whichever is greater
Exam modes
Exam selection
• Automatic selection for Adult and
Child, 3 Sizes
• 3 biting modes (Panoramic exam)
• Manual selection
Panoramic exam
• Standard panoramic
• Half panoramic Left/Right
• Ortho Rad panoramic
• Low dose panoramic
• Frontal dentition
• Bitewing Left/Right
• Bitewing Left and Right
TMJ (Temporal Mandibular Joint) exam
TMJ open and closed mouth
Sinus
Sinus P/A projection
