Service Manual – Technical characteristics
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
41
Volumetric 3D exams
Automatic selection for Adult and Child,
3 sizes chosen between: entire
Dentition, Mandibular Dentition,
Maxillary Dentition, Small Volumes
(frontal, premolar, molar), TMJ Left, TMJ
Right, Sinus
3D Dentition reconstructed volume
Entire volume ( * )
85 mm x 93 mm (Diameter x Height)
Mandibular and Maxillary volume ( * )
85 mm x 50 mm (Diameter x Height)
Small volumes
50 mm x 50 mm (Diameter x Height)
Extended volumes
116 mm x 103 mm (Diameter x Height)
Cephalometric exams
Lateral projections
formats 18x24 cm, 24x24 cm, 30x24 cm
and 18x18 cm, 24x18 cm, 30x18 cm
Antero-posterior projections
format 24x24 cm and 24x18 cm
Carpus exam
format 18x24 cm
Note of cephalometric image formats:
For user convenience, the ceph projections are named following the conventional format
of the film-cassettes (24 cm), although the vertical active area of the cephalometric
sensor is 22.8 cm.
( * ) In case collimator kit code 6604061200 is present,“In case the 80x80 limitation is
set, the values will change to: Entire volume 80 mm x 80 mm (Diameter x Height);
Mandibular and Maxillary volume 80 mm x 50 mm (Diameter x Height).)
Image magnification
Geometric
magnification
Magnification
after software
correction
Adult / Child standard Panoramic
1 : 1.28 (constant
over dentition
part)
1 : 1 (*)
TMJ open/closed mouth
1 : 1.25 (nominal)
1 : 1 (*)
Sinus
1 : 1.27 (nominal)
1 : 1 (*)
Cephalometric exams
1 : 1.1 (nominal)
1 : 1 (*)
Carpus exam
1 : 1.06 (nominal)
1 : 1 (*)
(*) Warning
The declared image magnification value is valid after proper software
calibration.
