Service Manual - Technical characteristics
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
Note
X-MIND prime 3D is based on a standard dentition and ascending rami
shape. This shape, based on statistical studies, establishes a form for the
dentomaxillofacial complex, adopted as "standard".
X-MIND prime 3D follows a rototranslation path which maintains the
magnification factor as stated in the Technical Characteristics of each
type of exam as constant along this "standard" shape only along the
dentition area. The patient’s anatomy can differ significantly from the
statistical model, so the magnification factor is not maintained and may
be different from the value stated. Based on experience and competence,
the user has to judge this variation. In any case, TMJ radiography cannot
be used to perform calculations of distances, angles etc. on the film.
