Acteon X-MIND prime 3D ceph - Ceph Driver Board A13 Leds; Ceph Sensor Power Supply Board A14 LED

Service Manual – Troubleshooting
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
157
9.1.6 Ceph Driver Board A13 LEDs
The following table shows the LEDs that are present on the Ceph Driver Board (A13),
their function and the recommended corrective action in case of defect. To locate
the LED, refer to the layout of the A13 board (see chapter 12 – drawing 7).
Led
Colour
Working
status
Failure
status
Main function
Corrective action
H1
Green
ON
OFF
+24V output
Check 24V on cable
X62 on CCU board.
See also Error E750
(paragraph 9.2.10.2)
H2
Green
ON
OFF
+24Vinput
Check 24V on cable
X62 on CCU board.
See also Error E750
( paragraph 9.2.7.1 )
9.1.7 Ceph sensor power supply board A14 LED
The following table shows the LED that is present on the Ceph Sensor Power board
(A14), its function and the recommended corrective action in case of defect. To
locate the LED, refer to the layout of the A10 board (see chapter 12 – drawing 8).
Led
Colour
Working
status
Failure
status
Main function
Corrective action
H1
Green
ON
OFF
+12V sensor
power supply
Check 24V on cable
X62 on CCU board.
Check connection
X76 to CCU
board.See also Error
E750 ( paragraph
9.2.7.1 ). Check
pogo-pins
connections)
