Service Manual – Corrective maintenance
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
11.3.1.3
Generator board (A2) fuse
The Generator board fuse F1, in case of overcurrent, cuts the Generator board main
power supply.
Fuse type: 1 A T (250V) TR5
Refer to chapter 12 – drawing 3 – for fuse position.
11.3.1.4
3D Power sensor board (A10) fuse
The 3D Power sensor board fuse cuts the 8-9V supplied by the board A10 to the 3D
sensor in case of overcurrent.
Fuse Type: 2 A FF (125V)
Refer to chapter 12 – drawing 4 – for fuse position.
