Acteon X-MIND prime 3D ceph - Page 131

Service Manual – Installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
129
5. Press the X-ray button to take an exposure and verify that the measured values
are in the acceptance limits listed in the Table at point 6.
6. Take a second exposure setting the following parameters: 86 kV, 12 mA, 3 s and
verify that the measured values are in the acceptance limits listed in the
following table.
Parameter
Acceptance range
kV
mA
t (s)
kV acceptance limits
Time acceptance limits
60
2
3
55.2 to 64.8 kV
2.85 to 3.15 s
86
12
3
79.1 to 92.8 kV
2.85 to 3.15 s
7. In case the test fails (result do not match the indicated values), proceed with
the following actions:
• Check the probe position and repeat the test
• If the values are still out of range, perform the test using the invasive
method as described in paragraph 7.13.1.
