Service Manual – Installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
134
Exposure values in Ceph LL mode
Adult Patient
(from 4.4 to 15.1 seconds)
Child Patient
(from 4.4 to 15.1 seconds)
kV
mA
kV
mA
Small
74
8
72
7.1
Medium
76
8
74
7.1
Large
78
8
76
7.1
Exposure values in Ceph AP mode
Adult Patient
(5.8 or 12.1 seconds)
Child Patient
(5.8 or 12.1 seconds)
kV
mA
kV
mA
Small
76
12.5
74
11
Medium
78
12.5
76
11
Large
82
12.5
78
11
Exposure values in Carpus mode
Child Patient
(4.4 seconds)
kV
mA
Small
62
8
Medium
62
8
Large
62
8
Note
The exam parameters set as the default are values to be taken as the
starting point. Users can optimise the parameters according to their needs.
Note
The type of biting does not affect the kV and mA values, but it affects the
position of the focus layer, by adapting rototranslation movement to the
patient’s anatomy.
