Service Manual – Troubleshooting
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
188
9.2.7.4 E753: Overload on Anodic current
This message is displayed when an abnormal value of the anodic current has been
detected.
With the unit switched OFF (at least for 4 minutes), perform the following tests:
1. Check that connectors X56 and X57 are well connected: connect it and verify if
the error is still present.
2. With connector X57 CONNECTED, using a multimeter, perform the measures
listed in the following table:
Parameter
Connection
Value
Feedback mA
X57-4(GND) and X57-1
326 Ω ÷ 334 Ω
3. With the connector X57 DISCONNECTED perform the measures (connector
side) listed in the following table:
Parameter
Connection
Value
Feedback mA
X57-4(GND) and X57-1
326 Ω ÷ 334 Ω
IF values measured at point 2. And 3. Are incorrect, replace the tubehead (see
paragraph 11.3.9) and the Generator board.
IF value measured at point 2. Is incorrect and value measured at point 3. Is correct,
replace the Generator board.
IF value measured at point 3. Is incorrect and value measured at point 2. Is correct,
replace the tubehead.
IF the tests listed at point 1., 2. And 3. Do not solve the error, replace the Generator
board and then the tubehead.
