Service Manual Troubleshooting
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
190
If the error is displayed, contact Technical Service.
9.2.7.8
E757: Brown out alarm /
E766: Generator board reset due to a brown-out /
E767: Generator board reset due to a low voltage detection /
E768: Generator board reset due to a watchdog timeout /
E769: Generator board reset due to a stack overflow
These messages are displayed when the Generator board microcontroller is reset
due to the displayed issue.
If the error is displayed, contact Technical Service.
9.2.7.9
E758: Alarm No X-ray /
E761: Alarm No X-ray emission
These errors are displayed when the anodic current has been interrupted during
or at the beginning of the emission and may indicate that the Generator board is
in a safety status (eg. Due to a discharge inside the tubehead, a broken tube or any
other tubehead damage).
Error E761 may be displayed / associated with other errors (i.e. E362 and E760) that
can explain the main cause of the X-ray interruption occurred during the previous
exposure (refers also to the associated error paragraph).
In order to reset these errors:
1.
Switch OFF the unit and wait at least 4 minutes.
a.
Switch ON the unit, perform an exposure and verify if the error is still
present.
b.
Switch OFF the unit, wait at least 4 minutes and switch it ON again: verify
that the pre-heating parameters stored in the MCU EEPROM memory
matches the ones listed in the equipment parameters table (supplied as
paper copy with the unit documentation see paragraph 14.1) (see
paragraph 8.4); correct them and verify if the error is still present.
2.
With the unit switched OFF (at least for 4 minutes), verify the proper connection
of the connectors X56 and X57; fix them, switch ON the unit and verify if the
error is still present.
3.
With the unit switched OFF (at least for 4 minutes), perform the following tests:
a.
Verify the primary winding continuity (max Ohmic value ≤ 0.5) on the pins
X56-1 and X56-2
b.
Verify the filament continuity (max Ohmic value 0.5) on the pins X57-5
and X57-6
c.
Verify the mA feedback Ohmic resistance on the pins X57-1 and X57-4, it
should be between 326 ÷ 334.
