Service Manual – Corrective maintenance
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
(*) Note
Before replacing, a burned fuse or any other parts verify that there are no
short-circuit on motors (M3, M4, M5, M6) and theirs cables as described in
the troubleshooting of the Errors E200 ÷ E205 (paragraph 9.2.3.1), E240 ÷
E243 (paragraph 9.2.3.3) and E265 ÷ E268 (paragraph 9.2.3.4). Verify also
that there are no short-circuit on cable X11-X37.
