Service Manual - Description
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
28
MCU board, CCU board and HF board are equipped with a local microcontroller that
shares information using a CANbus transmission line and protocol.
An additional power supply assembly (G2) is directly connected to the column
driver.
