Light indicator "X-Ray Emission" status. It indicates
the emission of X-rays.
Light indicator of "Computer connection" status:
•
Blue fixed, computer connection established
•
Blue blinking slowly, waiting for computer
connection. No X-ray emission available
•
Blue blinking fast, the equipment is in error
state. Refer to the GUI for error description.
The "Centring/Patient Entrance" key is used to:
•
Start/Stop the exam procedures
•
Put the rotation arm in the patient entrance
position at the end of the exam.
Temple clasps closing/release knob.
Chin rest control LED:
•
White fixed, the chin rest is correct for the
selected exam
•
White blinking, the chin rest is not present or
not correct for the selected exam
