Warning
It is responsibility of the installer to verify the type of wall and use the
correct fixing anchor.
Here following some suggestion that can help installer to find the correct
method depending on wall and installation type.
•
Standard wall installation .
Unit is fixed
using two screws on the
upper bracket and two screws on the lower bracket. Extraction
force on each anchor is about
55 kg
.
-
In case of full concrete (class C20/C25 thickness >200mm): drill
with Ø8 + Fischer Anchor FAZ II 8/10 (ordering code
6604100100). Tightening force 20Nm.
-
In case of full bricks: drill Ø14 + chemical Anchors FIS V-BOND
300T + Steel Insert FIS E 11X85 M6 + screws M6x25 (ordering
code 6604100200). This solution permit to avoid the use of
threated bars. Tightening force 4Nm.
-
In case of hollow brick: drill Ø16 + chemical Anchors FIS V-BOND
300T Plastic anchor FIS H 16X85 K + Steel Insert FIS E 11X85 M6
(ordering code 6604100200). This solution permit to avoid the
use of threated bars. Tightening force 2Nm.
•
Wall-floor installation. This installation is recommended when
the wall strength is uncertain.
Unit is fixed
using two screws on
the upper bracket, two screws on the lower bracket and four
screws on the base plate. Extraction force on wall anchors is about
46 kg
and on floor anchors is
73 kg
.
-
In case of full concrete (class C20/C25 thickness > 200mm): drill
with Ø8 + Fischer Anchor FAZ II 8/10 (ordering code
6604100100). Tightening force 20Nm.
-
In case of full bricks: drill Ø14 + chemical Anchors FIS V-BOND
300T + Steel Insert FIS E 11X85 M6 + screws M6x25 (ordering
code 6604100200). This solution permit to avoid the use of
threated bars. Tightening force 4Nm.
-
In case of hollow brick: drill Ø16 + chemical Anchors FIS V-BOND
300T Plastic anchor FIS H 16X85 K + Steel Insert FIS E 11X85 M6
(ordering code 6604100200 ). This solution permit to avoid the
use of threated bars. Tightening force 2Nm.
•
Wall installation with 16” adapter brackets (optional kit, p/n
6104101200).
Unit is fixed
using two screws on the upper bracket
and two screws on the lower bracket. Extraction force on each
anchor is about
25 kg
.
-
Anchors shall be chosen according to the wall stud material.
•
Free-standing floor plate (optional kit p/n 6104103000)
. No
fixation is necessary.
