6240B DC Voltage Current Source/Monitor Operation Manual
6.7.3 Remote Command List
6-39
Commands compatible with former models
Item Command Description
Default Operation
Power
ON
Factory
shipment
DC/pulse
OPR/SUS
Sweep
OPR/SUS
Source Function and
source range
V3 Voltage source function 300 mV range
Execut-
ing this
function
sets Sus-
pend.
V4 Voltage source function 3 V range
V5 Voltage source function 15 V range
I-1 Current source function 30 µA range
I0 Current source function 300 µA range
I1 Current source function 3 mA range
I2 Current source function 30 mA range
I3 Current source function 300 mA range
I4 Current source function 1 A range
I5 Current source function 4 A range
V? Response: V3 to V5 or I-1 to I5
I?
Source value
(pulse value)
and limit value
D  data UNIT The source value setting is different depending on
whether UNIT is specified or not.
With UNIT:
Automatically sets the optical range.
Available unit: mV, V, µA ,mA, A
Without UNIT:
Sets the present function and range.
When a unit that is different from that of the
present source function is set, the input data is set
as limit value as follows.
+data: HI limit value
-data: LO limit value
D? Response: D  <data1>UNIT,D <data2>UNIT
data1:Voltage or current source value
<d.ddddE ± d>
*1
data2:Voltage or current limit value
(The polarity is space.)
<0d.dddE  d>
*1
UNIT:V or A
*1: The decimal point position in response varies depending on the setting value.
For the source value, limit value, and time parameter setting ranges, refer to the specifications.
Note:
When the absolute values of HI and LO limit values
are different, the response becomes, D ± d.ddddE ±
dUNIT, D 09.999E + 9UNIT.
