ADCMT 6240B User Manual

6240B DC Voltage Current Source/Monitor Operation Manual
6.7.3 Remote Command List
6-38
Cali
bra
tion
Calibration switch CAL0 OFF (Exits the calibration mode.)
CAL1 ON (Enters the calibration mode.)
CAL? Response: CAL0 or CAL1
Calibration data XINI Initializes the calibration data.
(Not initializes the calibration data in the non-volatile
memory.)
XWR Saves the calibration data to the non-volatile memory.
Calibration
execution
XVS Selects the voltage source function calibration
XIS Selects the current source function calibration.
XVLH Selects the voltage limiter (High) calibration.
XVLL Selects the voltage limiter (Low) calibration.
XILH Selects the current limiter (High) calibration.
XILL Selects the current limiter (Low) calibration.
XVM Selects the voltage measurement function calibration.
XIM Selects the current measurement function calibration.
Calibration range
XR-1
XR0
XR1
XR2
XR3
XR4
XR5
Sets the calibration range.
Calibration data XDAT Changes to the DMM data input mode.
XD data: Inputs DMM read data.
XADJ Changes to the calibration data fine adjustment mode.
XUP Calibration data fine adjustment (UP)
XDN Calibration data fine adjustment (DOWN)
XNXT Moves to the next calibration.
*5: Not initialized by the RINI command.
*6: Not initialized by the RINI or *RST command.
Item Command Description
Default Operation
Power ON
Factory
shipment
DC/pulse
OPR/SUS
Sweep
OPR/SUS
Voltage range Current range
XR-1 - 30 A
XR0 - 300 A
XR1 - 3 mA
XR2 - 30 mA
XR3 300 mV 300 mA
XR4 3 V 1 A
XR5 15 V 4 A
