6240B DC Voltage Current Source/Monitor Operation Manual
9.1 Source and Measurement
9-7
Settling time: Time to reach the final value 0.1% when varying from zero to the full scale.
Setting conditions: Source values and limit values are full-scale settings.
Load conditions: Pure resistance load, and load capacitance of 200 pF or less
Typical value
Source
range
Limiter
range
Settling time
Output response
FAST SLOW
Voltage source
(Output current: 4 A
1 A in the 15 V range)
300 mV
4 A
200 s or less 1 ms or less
3 V 100 sor less 300 s or less
15 V 300 sor less 700 s or less
Current source
(Output voltage: 15 V
10 V in the 4 A range)
30 A
15 V
1.5 ms or less 2 ms or less
300 A
400 s or less 700 s or less
3 mA
30 mA
300 mA
1 A 1 ms or less 2 ms or less
4 A 450 s or less 700 s or less
Typical value
Source
range
Limiter
range
Settling time
Output response
FAST SLOW
Voltage source
(Output current: 20 % or less of full sale)
300 mV
3 mA to
300 mA
50 s or less 200 s or less
3 V 30 s or less 100 s or less
15 V 100 s or less 300 s or less
Current source
(Output voltage: 1 V)
300 A
3 V
50 s or less 100 s or less
3 mA
30 mA
300 mA
1 A 100 s or less 200 s or less
4 A 50 s or less 150 s or less
