6240B DC Voltage Current Source/Monitor Operation Manual
2.2.2 Setting Limit Values
2-22
3. Press NULL (SEL).
The cursor moves to the LL value, and the HL value is displayed at half-bright-
ness.
4. Move the cursor to 3.
5. Press or rotate one click counterclockwise.
The LL value changes, and the ranges for both the HL and LL values increase by
one at the same time.
Same polarity limit setting
If the Separate setting is selected, the HL and LL values for the voltage limiter can be
set to the same polarity.
However, the HL and LL values have the following restriction:
60 digits  (HL value -LL value)
1. Press MENU to select "Separate."
2. Press VS/IS to select the current function.
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
