ADCMT 6240B User Manual

6240B DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-32
NOTE: In Operate or Suspend status, only parameter items that can be set and executed are displayed.
1) Limit Buz Limiter detection buzzer
Off / On
Select
2) Compare Buz Comparator calculation result buzzer
Off / HI / GO / LO / HI or LO
Select
3) Notice Buz Process completion notice buzzer
On / Off
Select
4) Self Test Runs the selected self test.
Use or to select.
Press [ENTER] to run.
a) Self Test: Self test
b) Dsp/KeyTst: Display/key test
Select
Run
5) Error Log Reads out the error log.
a) NoXXXX=YYY
Use the rotary knob to change XXX.
YYY is the error number.
The lower line displays the error description.
Run
6) Relay Cnt Operate/Standby relay operation count Run
M) SYSTEM
Category level
Select level Input/Run level
Parameter
type
(e)
