6240B DC Voltage Current Source/Monitor Operation Manual
2.2.6 Pulse Measurement
2-41
22. Press and to change the source value (pulse value) to 2.5 V.
The measured current value with the pulse value of 2.5 V is displayed.
Current measurement with the base value
23. Follow step 11 to set the measurement delay time to 60 ms, and press MENU.
The HOME screen is displayed. (Td2)
The measured current value with the base value of 1 V is displayed.
(See Point B in Figure 2-16)
24. Follow step 7 to set the base value to 0.5 V, and press MENU.
The HOME screen is displayed.
The measured current value with the base value of 0.5 V is displayed.
To Next Page
