Troubleshooting Access Type TDM Channel Modules
LED
Name
LED Colors Potential Cause Solution for Troubleshooting
Mod Green Module provisioned,
admin state is
“Maintenance”,
“Management” or “In
Service”
No action is required.
Cx Red Pluggable transceiver
was inserted and
interface provisioned,
then the pluggable
transceiver was
removed.
Reinsert the pluggable transceiver.
P
in max
too high,
receiver damage
threshold exceeded
1 Measure the optical input power on the
receiver connector and compare the
measured value with the channel
module/pluggable transceiver specification.
2 Adjust the optical input power (i.e., install
the appropriate attenuators) to fulfill the
Optical Input Power requirements.
Yellow Loss of clock 1 Verify that the provisioned service type
matches the incoming signal type.
2 Check optical power measurements. Refer
to “Finding Your Problem - Follow the Light”
on p.53 in this document.
Signal degrade The number of bit/block errors exceeded the
configured threshold. To identify the failure
location, refer to the troubleshooting instructions
for the relevant signal degrade condition outlined
in Alarm and Event List.
Loss of character sync Unable to synchronize on the characters in the
incoming data stream.
1 Verify that fiber cables are connected.
2 Check optical power levels. Refer to
“Finding Your Problem - Follow the Light” on
p.53 in this document.
Loss of signal 1 Verify that fiber cables are connected.
2 Check optical power levels. Refer to
“Finding Your Problem - Follow the Light” on
p.53 in this document.
Table 41: LED Status of the 4TCA-PCN-4GU(S)+4G
