Replacing an Encryption Module
Step 12 If available, mount the front cover to the shelf, as described in “Mounting an
SH7HU, SH9HU, or SHX9HU Front Cover” on p.769.
Step 13 Detach the wrist strap from your wrist, and then disconnect the grounding
cable from the ESD grounding point on the shelf (if available) or the rack.
Step 14 Store the optical cables for future use.
Return any defective module to ADVA Optical Networking for repair, as
described in the Installation and Commissioning Manual.
If you encounter problems that result in a deviation from the procedure
described above, contact ADVA Optical Networking Technical Services.
Installing an Encryption Module
This section describes the procedure for adding encryption modules. For specific
information about each encryption module type, refer to the
Hardware Description
.
Note
Before connecting fiber-optic cables, install the encryption module and
pluggable transceivers to the FSP 3000R7 system, as described in this
section. After physical installation, the module boots.
Please wait about one minute until the boot, configuration, and
initialization time for protection completes. Then fiber-optic cables can
be connected to the installed encryption module and pluggable
transceivers.
CAUTION
Only Service Personnel are allowed to perform this procedure.
CAUTION
Only Service Personnel who is security-cleared may install the 10TCE-
PCN-16GU+AES100G-BSI module to the shelf.
Additional Information
Encryption modules are plug-in modules that are compatible with any FSP 3000R7 shelf.
Adding an encryption module does not affect the operation of currently installed modules
in the shelf. There are no fixed slot positions for specific encryption modules. Encryption
modules can be inserted into a shelf slot without the use of any tools.
Encryption modules are provisioned with two independent sets of configuration
parameters:
• Optical parameters are controlled by the database on the NCU and are provisioned
automatically when the replacement module is inserted. Use management software
to confirm these settings. If the settings differ from your network requirements,
reconfigure the module, as addressed in “Provisioning a Network Element” in the
Provisioning and Operations Manual
.
