Fixed Gain-Controlled EDFA Modules
Fixed Gain-Controlled, Single-Stage EDFA Modules
Single-stage, fixed gain-controlled EDFA modules have three LEDs on their faceplate:
• “P” to indicate the power supply status
• “Mod” to indicate the operation status of the module
• “1” to indicate the amplifier port status
Note
Please note, the module should lose power for at least 10 seconds to allow any and all
capacitance to dissipate.
Note
If your module has an LED status that is not represented in Table 84, please contact your ADVA
Optical Networking Technical Services Representative.
LED
Name
LED Colors Potential Cause Solution for Troubleshooting
All LEDs Red A serious error in card
initialization.
Remove and reinsert the module. If the condition
continues, return the module to ADVA Optical
Networking for repair.
P Yellow Power abnormal
Off Power failure
Green Power is OK. No action is required.
Mod Yellow Not applicable.
Yellow
blinking to
off
Management
communication is broken.
1 Check the SCU and EDFA firmware versions.
Update the firmware if required.
2 If the issue is not resolved, remove and reinsert
the SCU.
If the LED is still blinking yellow to off, contact your
ADVA Optical Networking Technical Services
Representative.
Off Module admin state is
“disabled”.
1 In the case that the module is installed and
provisioned, check the admin state settings.
2 If the management displays “disabled”, change
the admin state to “In Service”.
Module admin state is
“unassigned”.
Module is not provisioned, start the provisioning
process.
Table 84: LED Status of Single-Stage, Fixed Gain-Controlled EDFA Modules
