Troubleshooting Shelves
OTDR Shelf LEDs
The OTDR/THC/2HU/AC (THC) and OTDR/8-OTH/1HU/AC (OTH) shelves are
equipped with LED indicators that provide operational status information about the
shelves. The front panel of the shelves display the LEDs for the OTDR. The LEDs are
labeled “THC”, “OTH”, , and “Server”.
Refer to the OTDR Installation, Provisioning, and Operations Manual for more information
about interpreting the LEDs and troubleshooting.
Figure 15: LED Indicators of the OTDR
FSP 3000R7 Maintenance and Troubleshooting Manual - Product Release 16.2 - Document Issue A 87
