Troubleshooting Management Modules
Note
If your module has an LED status that is not represented in Table 70, please contact your ADVA
Optical Networking Technical Services Representative.
CAUTION
The use of pluggable transceivers other than those approved by ADVA Optical Networking will
result in loss of safety approval for the FSP 3000R7. Pluggable transceivers not approved by
ADVA Optical Networking will not function properly. Depending on the channel module type, Rx
and Tx of the affected interfaces may be disabled automatically or not. Only approved Pluggable
transceivers will guarantee the behavior in conjunction with the channel module as specified.
LED
Names
LED Colors Potential Cause Solution for Troubleshooting
P Off Power source has failed.
The OSCM receives no
power.
Check the PSU LEDs.
• If the PSU LEDs do not light up green,
refer to “Troubleshooting Power Supply
Units” on p.88.
• If the PSU LEDs light up green, a
hardware error of the OSCM has occurred.
Replace the OSCM.
Green Power is ok. No action is required.
Mod Red Module major and critical
alarms
Check the fault management table.
Yellow blinking
to off
1
Management com-
munication to the module
has failed.
1 Check the SCU firmware version and
compare it to the SCU firmware version as
listed on the NCU. If they are different,
update the SCU firmware as described in
“Performing Other Software Update
Actions” on p.628.
2 Remove and insert the module.
If the LED is still blinking yellow to off, contact
your ADVA Optical Networking Technical
Services Representative.
Green Module is enabled; no
alarms
No action is required.
Off Module admin state is
unassigned.
• If the management displays “Unassigned”,
check if the OSCM is provisioned in the
management.
• If the OSCM is not provisioned, create the
OSCM.
Table 70: LED Status of the OSCM
1
This indication applies only to OSCM-PNv2 modules.
