RAMAN-C10 Module
RAMAN-C10 Module
This subsection will help you resolve issues that might be experienced with the RAMAN-C10 module. It is assumed that the measurements for all interfaces are within
ADVA Optical Networking specifications. If not, refer to “Finding Your Problem - Follow the Light” on p.53 in this document.
CAUTION
Follow all the instructions precisely. If you do not supply the specified attenuation on given steps, you will destroy the module being tested.
Note
If your module has an LED status that is not represented in Table 88 on p.460, please contact your ADVA Optical Networking Technical Services
Representative.
The RAMAN-C10 module has three LEDs on its faceplate:
• “P” to indicate the power supply status
• “Mod” to indicate the operating status of the module
• “N” to indicate the relative operating status of the network port and the upgrade port
Note
Please note, the module should lose power for at least 10 seconds to allow any and all capacitance to dissipate.
FSP 3000R7 Maintenance and Troubleshooting Manual - Product Release 16.2 - Document Issue A 459
